The pressure transmitter board is an important part of the pressure transmitter production process, and it plays a key role in the performance, life, stability and other parameters of the entire transmitter. Pressure transmitter board parameters : -25 degrees to +85 degrees, temperature drift: ≤1×10 -4 FS/degree, non-linear error: ≤0.005% FSR. Long-term stability: ≤ 0.05%/year, storage humidity: 90% Application: diffused silicon, ceramic piezoresistive, sputtered film, strain gauges, etc. Magnified chips are products of well-known semiconductor companies imported from the United States Divided into: ordinary type, enhanced anti-jamming, triple lightning protection, digital intelligence. Supply voltage: 12~36VDC , standard 24VD (battery power supply) Operating temperature: - 30 to + 85 °C Output signal: 4~20mA (two-wire system); 0-10 mA , 0-20 mA , 4-20 mA (three-wire system) 1~5VDC (three-wire system); 0~5VDC (three-wire system), 1-10v, 0~10VDC (three-wire system); RS485 communication, HART protocol, etc. Pressure transmitter board selection: 1 Two-wire 4-20mA current type pressure transmitter circuit board (Other size circuits can be customized upon request) Pressure amplification board type Applicable housing model output signal Diffusion Silicon Circular Plate Current Type 2088, BP11, 133 housing RC-A2R 4-20mA Diffused Silicon Square Plate Current Type 131 shell, rod stainless steel RC-K2 4-20mA Hessian structure shell, input type Ceramic disc current type 2088, BP11 , 133 shells RC-A2R 4-20mA Ceramic square plate current type 131 shell, rod stainless steel RC-K2 4-20mA Hessian structure shell, input type 2 three-wire 0-10V / 0-5V / 1-5V DC / 1-10V voltage type pressure transmitter circuit board amplifier board (Other size circuits can be customized as required) Pressure transmitter circuit board type Applicable housing model output signal Diffusion type silicon disc voltage 2088, BP11, 133 housing RC-V2R 0- 5 V / 10V, etc. Diffused Silicon Square Plate Voltage Type 131 shell, rod stainless steel RC-V2 0- 5 V / 10V, etc. Hessian structure shell, input type Ceramic disk voltage type 2088, BP11 , 133 shells RC-V2R 0- 5 V / 10V, etc. Ceramic square plate voltage type 131 shell, rod stainless steel RC-V2 0- 5 V / 10V, etc. 3 Digital Intelligent Pressure Transmitter Board Selection: Sensor core type Applicable housing model output signal Diffused silicon, ceramic piezoresistive, sapphire, sputtered film 2088, BP11, 133 housing RC-LED01AP 4-20mA , LED display 131 shell, rod stainless steel RC-D01AP 4-20mA Hessian structure shell, input type Diffused silicon, ceramic piezoresistive, sapphire, sputtered film 2088, BP11, 133 housing RC-LED01DP RS485 communication, LED display 131 shell, rod stainless steel RC-D01DP RS485 communication Reference editing area This diameter of this series glass bead is two or three times bigger than regular beads. The surface part beyond paints is higher than regular beads; hence the reflectivity of road marking has been increased, especially in rainy, foggy areas.
